NPE 31-B/2 SAE3 d6.5

Phase: Single phase / Three phase
Maximum three phase power: 10.5 KVA
Maximum single phase power: 7 KVA
Frequency: 50 Hz
Voltage: 230 V / 400 V
Protection: IP21
Rpm speed: 3000 rpm
Poles: 2
Efficiency: 78.5%
Weight: 81 Kg
Constant speed alternator
Brushless
Voltage regulator: AVR

Download Technical Data NPE 31-2

Phase
Single phase / Three phase
Maximum power single phase (KVA)
7
Maximum power three phase (KVA)
10.5
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine rpm (rpm)
3000
Poles
2
Single-phase power (KVA)
7
Three-phase power (KVA)
10.5
Efficiency (%)
82.2
Protection degree
IP21
Acoustic pressure
75 dB(A) at 7 m
Brushes
No
PMG
No
Type of alternator
Constant Speed
Voltage regulator
AVR
Weight (Kg)
83
Precision of voltage regulation
± 1%
Brand

NPE31 2 pole generator

MECC ALTE NPE 31-B/2 THREE PHASE ALTERNATOR 10.5 KVA AVR

The NPE31 range has many product features designed into the alternator.
Self-regulation is obtained through a digital electronic regulator that is fed by an auxiliary winding.
We guarantee an almost constant supply from the generator – under any possible operating condition.
A rotating inductor is fitted with a damper cage.
The windings have a 2/3 pitch in order to reduce the harmonic content of voltage.
The entire series is manufactured according to, and complies with, the most common specifications such as CEI 2-3, IEC 34-1, EN 60034-1, VDE 0530, BS 4999-5000, CAN/ CSA-C22.2 No14-95- No100-95.



Not binding images and technical data.

Complete your order with:

Available only upon request
€1,724.57 €1,724.57
Choose the type of coupling
  • SAE3 disk joint 6.5
  • SAE3 disk joint 7.5
  • SAE3 disk joint 8
  • SAE3 disk joint 10
  • SAE3 disk joint 11.5
  • SAE4 disk joint 6.5
  • SAE4 disk joint 7.5
  • SAE4 disk joint 8
  • SAE4 disk joint 10
  • SAE4 disk joint 11.5
  • SAE5 disk joint 6.5
  • SAE5 disk joint 7.5
  • SAE5 disk joint 8
  • SAE5 disk joint 10
  • SAE5 disk joint 11.5

To purchase this product, you need to request a personalized quote. Contact us and we will provide you with all the necessary information within 24 hours.
