SINCRO FT 4-48/200 Synchronous DC Alternator 9.6 KW AVR

Name: SINCRO FT 4-48/200 Synchronous DC Alternator 9.6 KW AVR
Brand: SINCRO
SKU: FT 4-48/200
Price: 1201 EUR
Availability: InStock

Reference FT 4-48/200

Poles: 4
Voltage (V): 48
Frequency (Hz): 50
Rpm Speed: 1500
Power (KW): 9.6
Current (A): 200
Constant Speed Alternator
AVR
Brushes
Weight (Kg): 59.2
Protection: IP23

Download Technical data 24 & 48 VDC

Product Details
Description

Frequency (Hz): 50
Voltage (V): 48
Engine rpm (rpm): 1500
Poles: 4
Power (KW): 9.6
Protection degree: IP23
Current (A): 200
Brushes: Yes
Type of alternator: Constant Speed
Voltage regulator: AVR
Weight (Kg): 59.2

Brand

Designed for applications requiring 24 & 48 VDC low voltage supply, Sincro DC power solutions are suitable both as battery chargers and emergency power supplies of auxiliary circuits, in the telecommunication, transports and industrial field.

Applications
- Battery chargers
- Low voltage LED light towers
- Power supply of auxiliary circuits, high/medium voltage disconnectors coils, signalling devices
- Power supply of monitoring and alarm systems

General features
- AVR electronic voltage regulation
- Based on three-phase synchronous alternators
- 1500 rpm or 3000 rpm with large speed tollerance
- Constant DC output voltage
- Adjustable output voltage
- Current overload protection
- Fan cooled
- Complying with EN 60034-1, IEC 60034-1, ISO 8528-3

Sectors of use
- Telecommunications
- Industry
- Transports
- Military

Advantages
- High voltage stability in a large speed range
- High efficiency
- Low voltage ripple
- High reliability
- Available with the most common couplings
- Fast recovery time during transient by step load variation

Not binding images and technical data.
