GENERATING SET 1020KVA

Reference 1020KVA

Phase type: Three-phase
Maximum three-phase power: 897,6 KW / 1122 KVA
Three-phase continuous power: 816 KW / 1020 KVA
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Motor: BAUDOUIN 12M26G1100/5
Engine speed: 1500 rpm
Starting: Electric
Consumption: 154 Lt/h at 75% load
Length: 5450 mm
Width: 2200 mm
Height: 2550 mm
Weight: 8890 Kg
Super-silenced

Product Details
Description

Phase: Three phase
Maximum power three phase (KW): 897,6
Continuous power three phase (KW): 816
Maximum power three phase (KVA): 1122
Continuous power three phase (KVA): 1020
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Sockets configuration: Terminal box
Engine: BAUDOUIN 12M26G1100/5
Emissions Regulations: Stationary Use
Engine rpm (rpm): 1500
Speed governor: Electronic
Starting system: Electric
Engine capacity (cm³): 31800
Number cylinders: 12
Cooling: Water
Alternator: Brushless
Poles: 4
Protection degree: IP44
Bore x stroke (mm): 150 x 150
Consumption (L/h): 154 at 75% of the load
Acoustic pressure: 70 dB(A) at 7 m
Length (mm): 5450
Width (mm): 2200
Height (mm): 2550
Dry weight (Kg): 8890
Silenced: Yes
Super silenced: Yes
Product type: Generator
Voltage regulator: AVR
Engine manufacturer: Baudouin

Brand

Three-phase 1020KVA generator

Technical characteristics of the generator:

If you are looking for a similar product then you can browse the entire range of generators or other types of products in our catalogue to find the one that best suits your needs.

Images and technical data are not binding.
