PRAMAC GBW15Y APERTO CON QUADRO COMANDO AUTOMATICO

Name: PRAMAC GBW15Y APERTO CON QUADRO COMANDO AUTOMATICO
Brand: PRAMAC
SKU: SH130TYAK02 /

Reference SH130TYAK02 /

OUT OF PRODUCTION

Potenza Consumo uso continuativo: 13 kva
Tipo carburante: Diesel
Capacità serbatoio carburante: 51 LT
Autonomia: 18 h al 75% del carico
Dimensioni: L 160 cm x L 87 cm x A 95 cm
Peso a secco: 390 Kg

Download Scheda tecnica GBW15Y APERTO Download Technical data GBW15Y OPEN Download Disegno installazione GBW15Y

Product Details
Description

Phase: Three phase
Maximum power three phase (KW): 11.44
Continuous power three phase (KW): 10.4
Maximum power three phase (KVA): 14.3
Continuous power three phase (KVA): 13
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Sockets configuration: 1 x 400V 32A 3P+N+T CEE
Engine: Yanmar 3TNV88-BGPGE, naturally aspirated
Emissions Regulations: Stage 5
Engine rpm (rpm): 1500
Speed governor: Mechanical
Starting system: Electric
Engine capacity (cm³): 1642
Number cylinders: 3
Cylinders' position: In line
Oil capacity (L): 6.9
Cooling: Water
Alternator: Linz E1S13MD, with brushes
Poles: 4
Fuel tank capacity (L): 51
Consumption (L/h): 2.8 at 75% of the load / 3.8 at 100% of the load
Running time (h): 18 at 75% of the load / 13.5 at 100% of the load
Length (mm): 1600
Width (mm): 870
Height (mm): 950
Dry weight (Kg): 390
Silenced: No
Super silenced: No
Product type: Generator
ATS Switch device: Optional ATS
Voltage regulator: Compound
Engine manufacturer: Yanmar

Brand

Motore Diesel. Raffreddamento ad acqua. Silenziatore industriale. Base forcabile con carrelli. Liquidi motore e batteria carica. Quadro manuale MCP fornito di serie con 5 prese

L'immagine è puramente indicativa
