CGM V20KH Generator Set with Automatic Control Panel 400V STAGE5 22KVA

CGM V20KH Generator Set with Automatic Control Panel 400V STAGE5 22KVA

TheCGM V20KH Generator Set with Automatic Control Panel 400V STAGE5 22KVA is a high-performance professional solution designed for industrial and residential applications requiring reliability and constant power. Equipped with a Kohler KDI 1903 M 3-cylinder, water-cooled diesel engine, it guarantees efficient and long-lasting operation at 1500 rpm in full compliance with the Stage 5 emissions regulations.

This generator delivers a maximum three-phase power of 22 kVA (17.6 kW) and a continuous power of 20 kVA (16 kW), with AVR voltage regulator to maintain output stability even under variable loads. The self-excited brushless alternator ensures low maintenance requirements and a long life.

Equipped with a 400 V three-phase connection terminal block, the generator has an electric start and can be configured with an optional ATS switch panel for automatic start in the event of a mains failure. The 55-litre tank guarantees an autonomy of approximately 13.4 hours with a consumption of 4.1 L/h at 75% load.

Thanks to the silenced cabin, the noise level is kept to just 68 dB(A) at 7 metres, making it suitable even for use in noise-sensitive environments. With compact dimensions (1580 x 735 x 1105 mm) and a dry weight of 575 kg, the CGM V20KH combines power, efficiency and practicality in a single device.
If you are looking for a product like the CGM v20KH-C20 then you can consult the entire range of CGM generators or other types of products in our catalogue to find the one that best suits your needs.

Technical Features:

Phase type: Single phase / Three phase
Maximum three-phase power (kW): 17.6
Continuous three-phase power (kW): 16
Maximum three-phase power (kVA): 22
Continuous three-phase power (kVA): 20
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Socket configuration: Terminal block
Engine: Kohler KDI 1903 M
Engine speed (rpm): 1500
Speed ??governor: Mechanical
Starting: Electric
Displacement (cm³): 1861
Number of cylinders: 3
Cooling: Water
Alternator: Self-excited, brushless
Number of poles: 4
Fuel tank capacity (L): 55
Consumption (L/h): 4.1 at 75% load
Autonomy (h): 13.4
Sound pressure: 68 dB(A) at 7 m
Length (mm): 1580
Width (mm): 735
Height (mm): 1105
Dry weight (kg): 575
AVR: Yes
Silenced: Yes
Bore x stroke (mm): 88 x 102
Protection rating: IP44
Product type: Generator set
ATS switch panel: Optional
Voltage regulator: AVR
Engine brand: Kohler
Emissions standard: Stage 5
