TECNOGEN JD275TSS Generator
JD275TSS
Maximum three-phase power: 220 KW
Maximum three-phase power: 275 KVA
Fuel: Diesel
Voltage: 400V
Engine: John Deere 6081HF001
Starter: Electric
Length: 3830 mm
Width: 1130 mm
Height: 2000 mm
Weight: 2750 Kg
- Phase
- Three phase
- Maximum power three phase (KW)
- 220
- Maximum power three phase (KVA)
- 275
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Engine
- HONDA GC160
- Engine rpm (rpm)
- 1500
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 8100
- Number cylinders
- 6
- Cooling
- Water
- Fuel tank capacity (L)
- 306
- Consumption (L/h)
- 35.9
- Running time (h)
- 6.9
- Acoustic pressure
- 70 dB(A) at 7 m
- Length (mm)
- 3830
- Width (mm)
- 1130
- Height (mm)
- 2000
- Dry weight (Kg)
- 2750
- Silenced
- Yes
- Super silenced
- Yes
- ATS Switch device
- Optional ATS
- Voltage regulator
- No
- Engine manufacturer
- John Deere
- Brand
-
TECNOGEN JD275TSS SuperSilenced Generator
The TECNOGEN JD275TSS Generator is a super-silenced, 1500 rpm, water-cooled diesel generator set with a maximum three-phase power of 220 kW (275 kVA). It is designed and built for professional use even in particularly harsh working situations.
The engine is a John Deere 6081HF001, which is known for its quality and reliability. The alternator is a Leroy Somer, which is an absolute benchmark in the industry.
The dimensions of the TECNOGEN JD275TSS Generator supersilenced generator set are 3830 mm in length, 1130 mm in width and 2000 mm in height. The weight is 2750 kg.
The casings of the TECNOGEN JD275TSS Generator are made entirely of hot-galvanised steel and then painted with polyester powders, making them practically impervious to atmospheric agents.
The TECNOGEN is equipped with a complete electrical distribution board, which includes numerous watertight sockets, three-phase and single-phase, protected by separate magneto-thermal circuit breakers and the 0.03 A differential circuit breaker.
The main advantages of the TECNOGEN JD275TSS Generator Supersilent include:
Maximum three-phase power of 220 kW (275 kVA)
John Deere 6081HF001 diesel engine
Leroy Somer alternator
Compact dimensions
Low weight
Hot-dip galvanised steel casings
Complete electrical distribution box
The TECNOGEN JD275TSS is an ideal choice for professional applications requiring a powerful, reliable and quiet genset.
Here are a few additional details that can be included to 'pump up' the text:
The genset is capable of supplying electricity to power domestic, industrial or commercial consumers.
It can be used in the event of blackouts or in situations where the electricity grid is unavailable.
It is ideal for applications requiring high power, such as construction, agriculture or building.
It is equipped with an overload and short-circuit protection system, making it safe to use.
Technical characteristics TECNOGEN JD275TSS supercharged generator set:
Maximum three-phase power: 220 KW
Maximum three-phase power: 275 KVA
Fuel: Diesel
Voltage: 400V
Engine: John Deere 6081HF001
Starter: Electric
Length: 3830 mm
Width: 1130 mm
Height: 2000 mm
Weight: 2750 Kg
If you are looking for a TECNOGEN JD275TSS or with similar characteristics click HERE.
Images purely indicative.
