PRAMAC GBW15P APERTO CON QUADRO COMANDO MANUALE (MCP)

Name: PRAMAC GBW15P APERTO CON QUADRO COMANDO MANUALE (MCP)
Brand: PRAMAC
SKU: SH130TPAU00 /

Reference SH130TPAU00 /

OUT OF PRODUCTION

Maximum power Three-phase: 11.28 KW
Power continuous use Three-phase: 10.18 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Perkins 403D-15G
Starting: Electric
Consumption: 3.6 Lt/h at 100% of the load
Length: 1600 mm
Width: 870 mm
Height: 950 mm
Weight: 390 Kg
Compound

Download Scheda tecnica GBW15P APERTO Download Technical data GBW15P APERTO

Product Details
Description

Phase: Three phase
Maximum power three phase (KW): 11.28
Continuous power three phase (KW): 10.18
Maximum power three phase (KVA): 14.1
Continuous power three phase (KVA): 12.72
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Sockets configuration: 1 x 400V 32A 3P+N+T CEE - 1 x 400V 16A 3P+N+T CEE - 2 x 230V 16A 2P+T CEE - 1 x 230V 16A SCHUKO
Emissions Regulations: Stationary Use
Speed governor: Mechanical
Starting system: Electric
Engine capacity (cm³): 1496
Number cylinders: 3
Cylinders' position: In line
Oil capacity (L): 6
Cooling: Water
Alternator: Linz E1S13MD, with brushes
Poles: 4
Fuel tank capacity (L): 51
Consumption (L/h): 2.7 at 75% of the load / 3.6 at 100% of the load
Running time (h): 18.6 at 75% of the load / 14.2 at 100% of the load
Length (mm): 1600
Width (mm): 870
Height (mm): 950
Dry weight (Kg): 390
Silenced: No
Super silenced: No
Product type: Generator
ATS Switch device: No ATS
Voltage regulator: Compound
Engine manufacturer: Perkins

Brand

The GBW series offers reliable and powerful machines, built for professional use in support of the power grid in case of blackouts or to serve isolated locations.
Easy to transport, install and position thanks to its compact size, this model is ideal for network emergency, construction, mobile workshops and industrial applications.
Available in open or hooded version.

Images are purely indicative.
