PRAMAC GBW35Y APERTO CON QUADRO COMANDO MANUALE (MCP)

Name: PRAMAC GBW35Y APERTO CON QUADRO COMANDO MANUALE (MCP)
Brand: PRAMAC
SKU: SH260TYAQ00 /

Reference SH260TYAQ00 /

OUT OF PRODUCTION

Maximum power Three-phase: 26 KW
Three-phase continuous use power: 24.4 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98-IGPGE
STAGE IIIA
Starting: Electric
Consumption: 7.7 Lt/h at 100% of the load
Length: 2000 mm
Width: 920 mm
Height: 1100 mm
Weight: 558 Kg
AVR

Download

Product Details
Description

Phase: Three phase
Maximum power three phase (KW): 29.87
Continuous power three phase (KW): 28.38
Maximum power three phase (KVA): 37.34
Continuous power three phase (KVA): 35.48
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Sockets configuration: 1 x 400V 32A 3P+N+T CEE - 1 x 400V 16A 3P+N+T CEE - 2 x 230V 16A 2P+T CEE - 1 x 230V 16A SCHUKO
Engine: Yanmar 4TNV98-IGPGE, naturally aspirated
Emissions Regulations: Stage 3A
Speed governor: Mechanical
Starting system: Electric
Engine capacity (cm³): 3319
Number cylinders: 4
Cylinders' position: In line
Oil capacity (L): 10.5
Cooling: Water
Alternator: Mecc Alte ECP28-VL/4, brushless
Poles: 4
Fuel tank capacity (L): 51
Consumption (L/h): 5.8 at 75% of the load / 7.7 at 100% of the load
Running time (h): 8.8 at 75% of the load / 6.6 at 100% of the load
Length (mm): 2000
Width (mm): 920
Height (mm): 1100
Dry weight (Kg): 558
Inverter: No
AVR: Yes
Compound: No
Silenced: No
Super silenced: No
Product type: Generator
ATS Switch device: No ATS
Voltage regulator: AVR
Engine manufacturer: Yanmar
