HONDA HF 2317 HME Ride-on Lawnmower Turbofan Cutting deck 92 cm

HONDA HF 2317 HME Ride-on Lawnmower Turbofan Cutting deck 92 cm
HONDA HF 2317 HME Ride-on Lawnmower Turbofan Cutting deck 92 cm
HF 2317 HM E

BBC Blade stop control: Electromagnetic
Grass Catcher Bag Unloading: Manual
Positions and cutting: 7
Noise level: 100 dB(A)
Length: 2440 mm
Width: 970 mm
Height: 1230 mm
Dry weight: 218 kg
Cutting plate size: 92 cm
Number of blades: 2
Height adjustment: 30 - 80 mm
Grass catcher bag capacity: 280 Lt
Collection time per turf 100mq: 2 min 3 sec
Mulching time per turf 100mq: 0 min 48 sec
Power supply: Gasoline
Engine: Honda
Type: V-Twin OHC 4-stroke
Engine displacement: 530 cc
Engine model: GCV530
Rated motor power: 9.7 KW
Engine revolutions per minute: 2800
Fuel tank capacity: 5.4 Lt
Engine oil capacity: 1.3 Lt
Transmission type: Variable - hydrostatic
Feed speed: Progressive: from 0 to 8.2 Km/h
Tyres
Front wheels (diameter for width - edge): 13 x 5.0 - 6 (inches) (inches)
Rear wheels (diameter for width - edge): 18 x 8.5 - 8 (inches) (inches)
Radius of rotation: 1.8 m

Download Scheda tecnica HF 2317 HME

Fuel
Gasoline
Engine
Honda GCV530, V-Twin, OHC, 4-stroke
Engine rpm (rpm)
2800
Starting system
Elettrico
Engine capacity (cm³)
530
Oil capacity (L)
1.3
Speed (Km/h)
0-8.2
Transmission
Hydrostatics
Fuel tank capacity (L)
5.4
Acoustic power
100 dB(A)
Dry weight (Kg)
218
Turning radius (mm)
1800
Cutter deck size (mm)
920
Grass bag capacity (Litres)
280
Lawn size suggested
Over 500 square meters
Mulching System
Optional
Cutting Height Positions
7
Grass collection time per 100 m² turf (min:sec)
02:03
Time for mulching grass for 100 m² turf (min:sec)
00:48
Cutting height (mm)
30-80
Grass bag dumping
Manual
Blades
2
Speeds
Variable Speed
Traction type
Hydrostatic
Product type
Lawn tractor
Engine manufacturer
Honda
Brand

HONDA HF 2317 HME RIDE-ON LAWNMOWER TURBOFAN CUTTING DECK 92cm

HONDA HF2317HME ltractor designed with a new type of engine, more docile, fluid and easy to drive. Beautifully finished, HONDA HF2317HME  is built to give you a beautiful lawn. This sturdy mower is suitable for large lawns and gardens and offers a precise cut with 92 cm blades, hydrostatic control & 280 litre grass catcher bag.

Technical Specifications HONDA HF2317HME:
BBC Blade stop control: Electromagnetic
Grass Catcher Bag Unloading: Manual
Positions and cutting: 7
Noise level: 100 dB(A)
Length: 2440 mm
Width: 970 mm
Height: 1230 mm
Dry weight: 218 kg
Cutting plate size: 92 cm
Number of blades: 2
Height adjustment: 30 - 80 mm
Grass catcher bag capacity: 280 Lt
Collection time per turf 100mq: 2 min 3 sec
Mulching time per turf 100mq: 0 min 48 sec
Power supply: Gasoline
Engine: Honda
Type: V-Twin OHC 4-stroke
Engine displacement: 530 cc
Engine model: GCV530
Rated motor power: 9.7 KW
Engine revolutions per minute: 2800
Fuel tank capacity: 5.4 Lt
Engine oil capacity: 1.3 Lt
Transmission type: Variable - hydrostatic
Feed speed: Progressive: from 0 to 8.2 Km/h
Tyres
Front wheels (diameter for width - edge): 13 x 5.0 - 6 (inches) (inches)
Rear wheels (diameter for width - edge): 18 x 8.5 - 8 (inches) (inches)
Radius of rotation: 1.8 m

Performance so enjoyable you won't want to stop
HONDA HF2317HME lawn mower does everything possible to meet your needs because we know that mowing the lawn is not a job, it's a passion. HONDA HF 2317 HME lawn mower is robustly built with durability and strength in mind. Together with hydrostatically controlled transmissions for smooth & precise control, you'll care for your garden in the easiest and most pleasant way.

Maximum control
Comfort is at your fingertips on HONDA HF2317HME with new ergonomically designed steering wheel. HONDA HF 2317 HME mower also features a steering knob that allows you to quickly turn the steering wheel to operate & manoeuvre near trees & bushes.

Stay charged
Does your phone need charging? No problem when working with a HONDA HF2317HME. Just plug it in and place device in the convenient holder to charge it while you take care of your lawn.

First class comfort
Particular care and attention to detail has been paid to design of seat, which is now the most comfortable ever. The material is durable and soft to the touch and this new design features folding armrests which further increases comfort level of HONDA HF2317HME.

A secure pocket
Practicality is one of strengths of HONDA HF2317HME. This simple and practical accessory allows you to keep your mobile phone always at hand & avoid risk of it accidentally falling while you are working.

Fluid performance
Optiflow® is unique airflow management system created by HONDA that offers superior collection performance with no more clogging of collection duct. Versamow® is also present, a system that allows selective mulching. It allows mulching while mowing the grass, helping to create a natural fertilizer for a healthier lawn.

Built to last
Anti-corrosion paint adds an elegant finish to sturdy steel cutting deck to give HONDA HF2317HME a more pleasant appearance for longer.

If you are looking for a lawn tractor similar to the HONDA HF2417HME but with different features? you can find our entire range HERE.
