HELVI MAKER211 PORTABLE WELDING MACHINE

Name: HELVI MAKER211 PORTABLE WELDING MACHINE
Brand: HELVI
SKU: 99805999
Price: 220 EUR
Availability: InStock

HELVI GALILEO 175 MMA/TIG Welding Inverter

Reference 99805999

Phase type: Single phase
Frequency: 50/60 Hz
Voltage: 230 V
Power 60%: 3.2 KW
Welding type: MMA
No-load voltage: 70 V
Current regulation: 10 - 200 A
Maximum current: 120 A
Working cycle at 40°C: 200 A @ 15% - 100 A @ 60% - 80 A @ 100%.
Working cycle at 20°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100%
Electrode diameter: 1,6 ÷ 5.0 mm
Electrode type: 6013 - 7018
Insulation: H
Degree of protection: IP22S
Length: 285 mm
Width: 120 mm
Height: 255 mm
Weight: 3.2 Kg

Download Data Sheet HELVI MAKER211

Product Details
Description

Phase: Single phase
Frequency (Hz): 50 / 60
Voltage (V): 230
Cooling: Air
Protection degree: IP22S
Motor insulation class: H
No-load voltage (V): 70
Regulation current (A): 10 ÷ 200 A
Welding current (A): 200
Amp. 60974-1 (40°): 200 A @15% • 100 A @ 60% • 80 A @ 100%
Diameter electrodes (mm): 1,6 ÷ 5.0
Maximum diameter electrodes (mm): 5.0
Type of welding current: DC
Type of welding: MMA / MIG
Current max (A)
Power consumption (W): 3200
Length (mm): 285
Width (mm): 120
Height (mm): 255
Voltage regulator: Inverter
Weight (Kg): 3.2

Brand

HELVI MAKER211

HELVI MAKER211 is a portable welder with inverter technology for electrode welding, ideal electrode diameter of 4.0 mm.

With HELVI MAKER211 you can weld with all commercial electrodes, the output is safe thanks to the internal protection systems, it protects itself in case of overvoltage and overcurrent.

The HELVI MAKER211 welder comes in a case complete with a 3.0-meter-long, 16mm2-section electrode cable, ground cable, and a plastic welding mask.

The HELVI MAKER211 is equipped with various devices to enhance welding, including:

The hot start device facilitates electrode initiation.

The arc force device automatically increases the welding current in case the arc is too short.

The Anti-sticking device that prevents the electrode from sticking to the workpiece.

The HELVI MAKER211 is suitable for use with any motor generator.

TECHNICAL FEATURES HELVI MAKER211

Phase type: Single phase
Frequency: 50/60 Hz
Voltage: 230 V
Power 60%: 3. 2 KW
Welding type: MMA
No-load voltage: 70 V
Current setting: 10 - 200 A
Maximum current: 120 A
Work cycle at 40°C: 200 A @15% - 100 A @ 60% - 80 A @ 100%
Work cycle at 20°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100%
Electrode diameter: 1.6 ÷ 5. 0 mm
Electrode type: 6013 - 7018
Isolation: H
Protection class: IP22S
Length: 285 mm
Width: 120 mm
Height: 255 mm
Weight: 3.2 kg
