CUMMINS ONAN 0541-1275-02 PTO Clutch Assembly 24 V

Name: CUMMINS ONAN 0541-1275-02 PTO Clutch Assembly 24 V
Brand: CUMMINS ONAN
SKU: 0541-1275-02

Reference 0541-1275-02

CUMMINS ONAN 0541-1275-02 PTO Clutch Assembly 24 V.
Suitable for Cummins Onan marine generators 24 VDC MDKBT/U.
Net Available Power at 1500 rpm: 40 HP (29.8 KWm)
Kit Includes: Clutch, instruction sheet, and brackets and hardware.

Download Technical Data 0541-1275-02

Product Details
Description

Frequency (Hz): 50 / 60
Voltage (V): 24
Mechanical power (hp): 40
Product type: PTO Clutch Assembly

Brand

CUMMINS ONAN 0541-1275-02 PTO Clutch Assembly 24V

Front power take-off (PTO) clutch with torsional coupling.

Description
PTO flexible coupling electric clutch to direct drive accessories.
SAE ‘B’ spline 13T 16/32 DP, 2 or 4 bolt pump mount.

Benefits
The PTO Clutch Assembly connects to drive accessories such as windlass or hydraulic thrusters.
The net available power varies by model and is limited by the maximum engine horsepower and maximum clutch engagement RPM.

Installation
Gensets without sound shield require belt guard kit.
Gensets with sound shield require “C” front panel.
