TELWIN EURARC 522 230V/400V

Name: TELWIN EURARC 522 230V/400V
Brand: TELWIN
SKU: 817018

Reference 817018

OUT OF PRODUCTION

Phase: Single phase / Three phase
Frequency: 50/60 Hz
Voltage: 230 / 400 V
Type of welding current: AC
Type of welding: MMA
No-load voltage: 52 - 71 V
Regulation current: 40 - 400 A
Current max: 350 A
Diameter electrodes: 1.6 - 6 mm
Length: 950 mm
Width: 490 mm
Height: 680 mm
Weight: 81 Kg

Download Manual EURARC Download Scheda tecnica EURARC 522 Download Technical data EURARC 522 Download Ficha técnica EURARC 522 Download Fiche technique EURARC 522

Product Details
Description

Phase: Single phase / Three phase
Frequency (Hz): 50 / 60
Voltage (V): 230 / 400
Protection degree: IP22
No-load voltage (V): 52 - 71
Regulation current (A): 40 - 400
Diameter electrodes (mm): 1.6 - 6
Type of welding current: AC
Type of welding: MMA
Current max (A): 350
Length (mm): 950
Width (mm): 490
Height (mm): 680
Weight (Kg): 81

EAN13: 8004897850924

Brand

MMA stick electrode welding machine in alternating current (AC). Stepless regulation of welding current.
With thermostatic protection.
The model has double secondary voltage for use also with basic and rutile electrodes.

Not binding images and technical data.
